Gutekunst VD-047C
Stock No:
#AD851827
- Article number: VD-047C;
Article description: Compression springs;
Material: 1.4310;
Spring ends: Angelegt;
Wire diameter [d]: 0.4 mm;
Inner coil diameter [Di]: - mm;
Mean coil diameter [D]: 4.6 mm;
Outer coil diameter [De]: 5 mm;
Maximum diameter of mandrel [Dd]: 3.8 mm;
Minimum diameter of bush [Dh]: 5.6 mm;
Unstressed spring length [L0]: 8.7 mm;
Buckling length [Lk]: mm;
Maximum force in static use [Fn]: 3.605 N;
Minimum length in static use [Ln]: 3.22 mm;
Maximum spring deflection in static use [sn]: 5.48 mm;
Maximum force in dynamic use [Fndyn]: 3.465 N;
Minimum length in dynamic use [Lndyn]: 3.43 mm;
Maximum stroke in dynamic use [shdyn]: 2.74 mm;
Pitch of spring [S]: 2.2 mm;
Number of active coils [n]: 3.5 pc.;
Total number of coils [nt]: - pc.;
Spring rate [R]: 0.658 N/mm;
Weight of one spring [Weight]: 0.079 g;
Price group: F
- Please contact us for detailed information about the Gutekunst VD-047C. If the product you are
looking for is not available on our website, you can request it from us. Let us
bring the product to you as soon as possible at the most affordable price.
Sold as:
Pack
Pack size:
12 pieces
